Atrial fibrillation: definitions, causes, risk factors, ECG diagnosis and management

Atrial fibrillation is the most common pathologic tachyarrhythmia (only sinus tachycardia is more common). Prevalence of atrial fibrillation correlates strongly with age. Approximately 10% of individuals aged 80 years and above have atrial fibrillation, whereas the arrhythmia is unusual among persons younger than 50 years of age. The overall prevalence in a Western population is 1.0% to 1.5%. The crude prevalence is lower in non-Western countries, primarily due to the younger age-composition in non-Western countries (adjusted prevalence figures are scarce). Indeed, the strongest risk factor for developing atrial fibrillation is age.

Other significant risk factors are as follows: male sex, hypertension, left ventricular hypertrophy, left ventricular dysfunction, valve disease, coronary artery disease, cardiomyopathy, congestive heart failure, congenital heart disease, diabetes mellitus (both type 1 and type 2), obesity, smoking, obstructive sleep apnea and chronic obstructive pulmonary disease (COPD). Moreover, certain other tachyarrhythmias predispose to developing atrial fibrillation: atrial flutter, AVNRT and AVRT (pre-excitation, WPW syndrome) being the most common.

Atrial fibrillation with debut during hyperthyroidism (thyrotoxicosis), alcohol overdose, thoracic surgery, acute myocardial infarction, pericarditis, myocarditis or pulmonary embolism is often a reversible arrhythmia with low risk of recurrence. Atrial fibrillation in the remaining circumstances (listed above) is usually a progressive disease.

The electrophysiological mechanisms underlying atrial fibrillation are discussed below.



Complications of atrial fibrillation and available treatments

In multivariable models individuals with atrial fibrillation are at five times increased risk of stroke and two times increased mortality, as compared with individuals without atrial fibrillation. The increased risk of stroke is explained by formation of thrombi in the left atrial appendage. Such thrombi may leave the appendage and enter the systemic circulation which causes thromboembolic occlusions of arteries in the brain, limbs or other organs. However, the increased risk in mortality is not completely explained by the increased risk of stroke; people with atrial fibrillation are at increased risk of cardiovascular mortality in general. This is not surprising given the adverse effects of long periods of tachycardia and desynchronized atrial and ventricular activity.

Fortunately, the treatment of atrial fibrillation has come a long way. Treatment with anticoagulation is highly effective in reducing stroke risk. Wrfarin and novel oral anticoagulants can reduce the risk of stroke by 70%, as compared with placebo. Besides anticoagulation, atrial fibrillation is treated with rate and/or rhythm control. Rate control implies the use of medications that slow ventricular rate (beta-blockers being the mainstay of this therapy). Rate control does not affect the rhythm per se. Rhythm control, on the other hand, attempts to restore sinus rhythm by use of antiarrhythmic drugs. Randomized controlled trials have not demonstrated any clear difference in mortality when comparing rate and rhythm control. However, rhythm control conveys risks (most antiarrhythmic drugs have a pro-arrhythmic effect as well), which is why clinicians mostly choose rate control. Both rate and rhythm control reduces morbidity, mortality and improves quality of life. These approaches are discussed further below.



Symptoms of atrial fibrillation

Approximately 25% of all individuals with atrial fibrillation are asymptomatic (they have no symptoms). In such individuals, screening with ECG may reveal atrial fibrillation. Unfortunately, atrial fibrillation is too often discovered first at hospital admission due to its complications (stroke, thromboembolism, heart failure, dyspnea). Most individuals, however, do experience symptoms and they do so before developing complications. Symptoms such as palpitations, dyspnea, fatigue, chest/throat discomfort and impaired exercise capacity are common and may all coexist. Dizziness is also common. Syncope, however, is uncommon. If a patient with atrial fibrillation experiences episodes of syncope or even pre-syncope, one must suspect tachy-brady syndrome, which implies that there is concomitant sinus node dysfunction. Atrial fibrillation debuting with congestive heart failure is uncommon among persons with previously normal left ventricular function.

Note that the tachyarrhythmia symptoms of atrial fibrillation (palpitations, chest discomfort etc) occur abruptly. and patients typically report that the palpitations started suddenly.



ECG in atrial fibrillation

The hallmark of atrial fibrillation is absence of P-waves and an irregularly irregular (i.e totally irregular) ventricular rate. The baseline (isoelectric line between QRS complexes) is characterized by either fibrillatory waves (f-waves) or just minute oscillations. Fibrillatory waves are small with varying morphology and high frequency (300 to 600 waves per minute). The amplitude of f-waves may vary from small to large. Large f-waves must not be mistaken for flutter waves (F-waves) which are seen in atrial flutter. It is, luckily, easy to distinguish these two because f-waves always show varying morphology whereas flutter waves are more or less identical (f-waves also have higher frequency than flutter waves). Figures 1 and 2 shows ECG examples of atrial fibrillation.



Figure 1. Atrial fibrillation with fibrillatory waves (f-waves).

Figure 1. Atrial fibrillation with fibrillatory waves (f-waves).



Figure 2. Atrial fibrillation without visible f-waves. Instead there is minute oscillations of the baseline.

Figure 2. Atrial fibrillation without visible f-waves. Instead there is minute oscillations of the baseline.



The ventricular rate is completely irregular, typically in the range of 100 to 180 beats per minute. The patients age, active medications and concomitant AV-blocks modify the ventricular rate. Atrial fibrillation with very rapid ventricular rate may appear as a regular rhythm (which is yet another reason to switch from 25 mm/s to 50 mm/s paper speed), which is why it is important to carefully measure the regularity of the rhythm. Refer to ECG in Figure 3. When in doubt, it is generally safe to apply carotis massage, which increases vagal activity to the atrioventricular node and thus increases blocking in the atrioventricular node; this lower ventricular rate and makes the irregularity more clear.



Figure 3. Rapid atrial fibrillation.

Figure 3. Rapid atrial fibrillation.



Atrial fibrillation does not affect the morphology of the QRS complex, provided that intraventricular conduction is normal. However, Ashamn’s phenomenon is frequently seen in atrial fibrillation. Ashman’s phenomenon is a special type of aberrant ventricular conduction, in which a bundle branch block occurs as a result of an abrupt change in the length of cardiac cycles. The ECG below shows an example of Ashman’s phenomenon.



Figure 4. ECG showing Ashman's phenomenon during atrial fibrillation.

Figure 4. ECG showing Ashman’s phenomenon during atrial fibrillation.



Classification of atrial fibrillation

Atrial fibrillation is classified according to the duration of the arrhythmia.

  • First diagnosed atrial fibrillation: Atrial fibrillation that hos not been diagnosed before, irrespective of its duration and symptoms.
  • Paroxysmal atrial fibrillation: Paroxysmal atrial fibrillation has a duration of less than 7 days. The arrhythmia is self-terminating in the vast majority of cases and it typically lasts less than 48 hours.
  • Persistent atrial fibrillation: lasts more than 7 days and generally requires intervention to be terminated.
  • Long-standing persistent atrial fibrillation: continuous atrial fibrillation lasting more than 12 months.
  • Permanent atrial fibrillation implies that the patient and the clinician has accepted the atrial fibrillation (usually after many attempts to induce cardioversion) and ceased attempts to restore sinus rhythm. This classification may be withdrawn if the patient and the clinician wishes to attempt restore sinus rhythm again.



Whether the arrhythmia converts to sinus rhythm spontaneously or by means of cardioversion (electrical or pharmacological) does not affect the classification. However, electrical and pharmacological cardioversion does limit the natural duration of the arrhythmia and may therefore affect the classification.

Atrial fibrillation is typically a progressive disease that usually evolves towards permanent atrial fibrillation. This is generally a stepwise process in which persons with paroxysmal atrial fibrillation tend to have an increasing number of episodes until the arrhythmia is persistent. Once persistent, the number of episodes with persistent atrial fibrillation tend to increase until the arrhythmia is long-standing persistent. It should be noted, however, that some patients have paroxysmal or persistent atrial fibrillation throughout their disease course, while others never return to sinus rhythm after a first diagnosis.

Treatment with ablation is only meaningful in paroxysmal or persistent atrial fibrillation. Treatment with anticoagulants, rate control or rhythm control should be considered in all types of atrial fibrillation.

Other types of atrial fibrillation

The term lone atrial fibrillation is used to describe a patient younger than 60 years of age, who do not have any other concomitant heart diseases or risk factors, and whose echocardiographic examination is normal. This type of atrial fibrillation has a good prognosis and generally do not require anticoagulation therapy.

The terms valvular and non-valvular atrial fibrillation are used to indicate whether the atrial fibrillation might be secondary to valvular disease. This has therapeutic implications as valvular atrial fibrillation is much more difficult to convert to sinus rhythm. It is generally not meaningful trying to cardiovert valvular atrial fibrillation as the vast majority wMeill relapse to atrial fibrillation shortly after cardioversion, if it succeeds at all.



Arrhythmias associated with atrial fibrillation

Arrhythmias associated with atrial fibrillation (WPW).



Mechanisms: atrial fibrillation begets atrial fibrillation

A large body of evidence demonstrate that atrial fibrillation in itself causes hemodynamic and electrophysiological changes in the myocardium which lead to increased susceptibility to new episodes of atrial fibrillation. Frequent and long-standing episodes of atrial fibrillation can thus create the prerequisites necessary for new episodes to emerge. These change are illustrated in Figure 5. Ultimately, the anatomic and electrophysiological changes will lead to permanent atrial fibrillation (as explained below).

Mechanisms and causes of atrial fibrillation.

Figure 5. Flow chart showing the development of atrial fibrillation and how it promotes continued fibrillatory activity.



Electrophysiological mechanisms of atrial fibrillation

The short story

The anatomic and electrophysiological mechanisms causing atrial fibrillation are still under investigation. The underlying mechanisms are somewhat complicated (discussed in detail below). For those not interested in electrocardiology, it is sufficient to know that atrial fibrillation is caused by an electrical chaos in the atria. The chaos is due to simultaneous existence of multiple re-entry circuits that generate impulse waves which propagate through the atria. These impulse waves collide with each other and with refractory cells, which fragments the waves and causes additional chaos. Interested readers may continue to read the detailed explanation to this.

The long story

Atrial fibrillation is dependent on two mechanisms: a trigger and a driver. The trigger is the event that initiates the atrial fibrillation and the driver is the mechanisms that will maintain the arrhythmia. The atria in individuals who develop atrial fibrillation display electrophysiological and anatomical properties which promote triggers and drivers. Aging, the strongest risk factor of atrial fibrillation, leads to degeneration of the myocardium and conduction cells. Other risk factors, such as structural heart disease (cardiomyopathy, heart failure, valvular disease), ischemic heart disease, pulmonary disease, genetic predisposition, autonomic dysfunction etc, are other risk factors that promote triggers and drivers. Studies unambiguously show that most triggers and drivers arise by the pulmonary veins that empty oxygenated blood into the left atrium.

The transition between pulmonary veins and atrial myocardium appears to be electrically vulnerable and studies show that the majority of patients with paroxysmal atrial fibrillation have a trigger by a pulmonary vein. The trigger is composed of an ectopic focus which discharges impulses at high rate. These impulses may induce short bursts of atrial fibrillation but unless a driver is established, the fibrillation will cease once the trigger stops discharging impulses. A driver may be established if the impulses spreading from the trigger encounters myocardium with varying conductivity or excitability. When the impulse encounters an area with varying conductivity/excitability, re-entry may arise due to blocking of the impulse. New impulse waves will spread from the re-entry and these waves may collide with other impulse waves and either be terminated or encounter new blocks which fragment the impulse. Fragmentation of the impulse will cause its remnants to spread in a random fashion through the atria. To sum up, paroxysmal atrial fibrillation is initiated by a trigger which discharges impulses at high frequency; impulses may encounter myocardium with heterogeneous or varying conductivity/excitability which may act as a block that give rise to re-entry circuits. These re-entry circuits beget additional re-entry circuits.

Early phases of atrial fibrillation (i.e paroxysmal and newly diagnosed atrial fibrillation) are characterized by featuring one or a few ectopic foci. Such focus/foci can be localized and eliminated by means or ablation therapy. This is generally a cure for atrial fibrillation, because elimination of the trigger will remove the initial cause. However, the number of ectopic foci and the number of generated re-entry circuits increase gradually as time goes and this correlates strongly with progression to persistent and long-standing persistent atrial fibrillation. For the same reason, ablation therapy is less effective in persons with persistent or long-standing persistent atrial fibrillation.

Mechanisms causing atrial fibrillation.



Besides the pulmonary veins, ectopic foci may be located by the entry of superior vena cava, inferior vena cava, the coronary sinus and the attachment of Marhall’s vein.

The autonomic nervous system appears to have an important role in inducing paroxysmal atrial fibrillation. One third of all individuals with paroxysmal atrial fibrillation experience their episodes in situations with high vagal activity (during sleep, at rest or high sympathetic activity (during exercise, stress etc). The autonomic nervous system modifies the action potentials in atrial myocardium, particularly around the pulmonary veins. However, the autonomic innervation of the atria is not homogenous (the spread of autonomic fibers in teh atria varies) which means that the effect on the action potentials is also not homogenous and this promotes atrial fibrillation.

Although atrial fibrillation is trigger by an ectopic focus in most cases, it may also be triggered by other arrhythmias such as AVRT or atrial flutter or even bradycardia. The latter (bradycardia) is believed to cause atrial fibrillation because at low heart rates ectopic focuses may come to express themselves when they are not suppressed by the sinoatrial node.

Examination of atrial fibrillation

Atrial fibrillation is verified on the ECG (resting ECG, Holter ECG, event recorder). Holter ECG may be used to assess the number of arrhythmia episodes and occurrences or asymptomatic episodes. If the patient may have coronary heart disease, exercise stress test (exercise ECG) should be considered. The following blood samples should be analysed: hemoglobin, sodium, potassium, creatinine, calcium, liver enzymes, lipids, glucose, HbA1c, thyroid stimulating hormone and T4. Echocardiography should be performed in virtually all cases of newly diagnosed atrial fibrillation. NT-pro-BNP may be analysed if heart failure is probable.



Management of atrial fibrillation

Treatment of acute atrial fibrillation

Approximately 60% of cases of acute atrial fibrillation will convert spontaneously to sinus rhythm within 16 hours from onset of symptoms. If there are no signs of circulatory compromise one may expect the situation for 48 hours (counting from symptom onset) until cardioversion is attempted. If one plans performing cardioversion it must be done within 48 hours from symptom onset. Cardioversion is contraindicated after 48 hours due to high risk of thromboembolism (unless a transesophageal echocardiogram can be performed to rule out thrombus formation in the atria (left atrial appendage). Electrical cardioversion is the most effective method, yielding a success rate of >90% with biphasic shock ≥200 J. Pharmacological cardioversion (flecainide, propafenon, ibutilid, amiodarone, vernakalant) are less effective (approximately 75% success rate) and these antiarrhythmic drugs may actually cause arrhythmias as well as circulatory compromise due to negative inotropic effect. In any instance, in any arrhythmia, it is always more safe to use electrical cardioversion than trying anything else.

Management (treatment) of atrial fibrillation.

One must immediately address whether the patient is in need of anticoagulants, and most patients should be admitted with a dose of low-molecular weight heparin until a decision has been made regarding anticoagulation.



Long-term treatment of atrial fibrillation

Rate control of atrial fibrillation

Rate control means that the ventricular rate is the treatment target. Beta-blockers, verapamil and digitalis are excellent choices to lower ventricular rate. Sotalol is reserved for cardiologists, as it has pro-arrhythmic effects as well. Rate control is not inferior to rhythm control in terms of hard outcomes. Aiming at a ventricular rate below 100 beats per minute can be recommended.

Rhythm control of atrial fibrillation

Rhythm control means attempting to restore sinus rhythm. This is done by means of anti arrhythmic drugs (sotalol, flecainid, propafenon, amiodarone, disopyramide, dronedarone). Rhythm control may be considered although most patients will relapse within one year and it does not provide a survival benefit as compared with rate control.

Catheter ablation

Ablation is a highly effective treatment for paroxysmal atrial fibrillation. There are usually one or a few ectopic foci that can be localized and eliminated with ablation therapy. Approximately 70% of paroxysmal atrial fibrillation cases may be cured with ablation therapy. Persistent atrial fibrillation has a more complex arrhythmia mechanism (more ectopic foci, more re-entry circuits spread throughout the atria, more atrial remodeling) and the effect of ablation is considerably poorer. roughly 50% of cases with persistent atrial fibrillation are cured with ablation therapy. Lung vein isolation is part of the treatment and aims to create a scar around the lung veins so that they become electrically isolated from the atrium.

Ablation therapy should be considered in all patients with symptomatic atrial fibrillation which is paroxysmal or persistent. The patient should have tried at least one anti arrhythmic drug prior to ablation therapy.

Although ablation therapy is a proven effective method, there is always a risk of future relapse.

Anticoagulation as profylaxis against thromboembolism

Stroke, transient ischemic attach and peripheral emboli are common in atrial fibrillation and must be addressed. The risk of thromboembolism is not, as previously believed, equal in all forms of atrial fibrillation. A recent meta-analysis by Ganesan et al (European Heart Journal (2016) 37, 1591-1602) showed that paroxysmal atrial fibrillation is associated with a  lower risk of stroke than persistent atrial fibrillation. However, the benefits of anticoagulation is equal in the two groups and both should be managed using the same treatment algorithms. Thus, current guidelines on anticoagulation in atrial fibrillation does not put forward any specific advice in relation to type of atrial fibrillation.

Begin by judging the risk of thromboembolism by using CHADS2-score and/or CHADS2-VASc-score. The risk of bleeding should be assessed using HAS-BLED score. Patients with a greater risk for thromboembolism than bleeding should be offered anticoagulation. The risk of stroke will be reduced by 70% using cheap anticoagulants as warfarin. Newer options (dabigatran, apixaban, rivaroxaban) are more expensive, equally effective in reducing stroke events, do not require monitoring of PK/INR and appear to cause fewer serious bleedings.
